Omni Standalone Reader Controllers
Standalone Biometric Terminals
One Device. Zero Compromises.
Most doors need multiple devices. You only need one. The Omni Standalone Reader Controllers combines palm, face, RFID, BLE, mobile wallet, QR code, and PIN authentication with a built-in video intercom and native visitor management powered by Cielo365 all in a single IP66-rated terminal.
Any Credentials, One Device
Access control, intercom, and visitor management in one device — no separate card reader, intercom panel, or visitor kiosk to wire, power, or integrate.
Palm and face authentication. Liveness detection. Anti-spoofing. Built for real-world conditions.
On-board relays, Wiegand I/O, and OSDP v2.2 give you full door control from a single mount — nothing else required.
Compliant where it counts. NDAA Section 889 approved, IEC EN 60839 Grade 4 certified, designed and engineered in the USA.
Omni connects natively to Cielo365 for cloud-based user management, visitor control, and intercom — no on-site servers required.
Talk To a Solutions Engineer
Slim 2.3″- wide reader controller for door, turnstile, and speed gate installs.
| Display | 2.4″ |
| Size | 58×19.5×185 mm |
| Weight | 327 g |
| Relays | 3× dry contact |
| Power | 12 VDC |
Slim Design & Mounting Options
Slim enough for any wall, versatile enough for any install. The Omni AC20 supports multiple mount types and includes speedgate accessories for high-traffic entry points.
IP66 Water & Dustproof Protection Rating
IP66-certified — built for outdoor deployment without compromise.
Advanced Security
AES-128 encryption protects data on the device and every communication between Omni and the software platform.
Supports Multiple Card Types
No credential left behind. Omni reads 125 kHz and 13.56 MHz across every major card type — EM, IC Card, HID Prox, iCLASS, MIFARE DESFire, Seos, and FeliCa.
Multi-Factor Authentication Capability
Multi-factor authentication across every credential type — palm, face, physical cards, mobile wallet, BLE, QR codes, and PIN. Supports IC Card, DESFire, HID Prox, iCLASS, and Seos, with QR scanning for both visitors and employees.
Video Intercom
Built-in video intercom handles visitor communication directly from the device — two-way audio with echo and noise cancellation for clear conversation in any environment.
Installation Made Easy
Designed for fast, clean installs. Slim profile and flexible mounting options mean less hardware and a cleaner wall. Speedgate accessories available.
| CPU | 1.2 GHz Quad-Core ARM |
| NPU | 2.4 TOPS |
| Memory | 8 GB + 1 GB RAM |
| Camera | Dual 2 MP CMOS · |
| Imaging | WDR, HDR, AE |
| Anti-spoofing | NIR · ISO 19795-2 |
| Cloud | Cielo365 (SaaS) |
| On-Prem | Armatura One |
| Transport | HTTPS push protocol |
| Visitor Management | Native QR + pre-reg |
| Legacy | Pro · SpeedFace |
| Standards | IEC EN 60839 Grade 4 |
| 125 kHz | EM · HID® Prox |
| 13.56 MHz |
IC · FeliCa |
| HID® |
iCLASS® · Seos® |
| MIFARE® |
Classic · DESFire® |
| Mobile | Apple · Google Wallet |
| Other | BLE · QR · PIN |
| Ethernet | 10/100 Mbps |
| PoE | AC30 only |
| RS-485 | OSDP v2.1.7 · 152 m |
| Wiegand | In/Out · 64-bit · 100 m |
| Encryption | TLS 1.2 · AES-128 |
| Power | 12 VDC · 3 A min |
| Rating | IP66 |
| Operating | −20°C to 60°C |
| Humidity | 10–95% RH |
| Housing | Aluminium + glass |
| Tamper | Magnetic detection |
| Certifications | CE · FCC · RoHS |
| Users | 50,000 |
| Face (1:N) | 10,000 |
| Palm (1:N) | 5,000 |
| Cards | 50,000 |
| Buffer | 1,000,000 events |
| Face Range | 40–140 cm |
Premium 5″-display reader controller with PoE and SIP video intercom for lobbies
| Display | 5″ 720p |
| Size | 97×209 mm |
| Weight | 835 g |
| Relays | 2× dry contact |
| Power | 12 VDC or PoE |
Modern Aesthetic Design
The build of the Omni AC30 blends a high quality metal enclosure with a tempered glass panel. The elegant design fits perfectly into any usage scenario and its sleek design brings a practical and reliable experience to users.
Industry-Leading Design and User Experience
The Omni AC30 provides an improved user experience with a 2.4" high resolution touchscreen screen and intuitive UI design. Using our advanced algorithms, users can get the best verification experience. Palm authentication distance range: 7" - 15.7" (18cm - 40cm) Face authentication distance range: 15.7"- 47.2"(40cm - 120cm)
Input Voltage
The device is compatible with 12V input voltage
Outdoor Rated for Variable Environments
IP66 Weatherproof rating - built to withstand freezing cold winters, heavy rains and dry/hot summers. -20°C to 60°C/ -4°F - 140°F operating temperature enables operation even under the most severe weather conditions.
Unrivaled Palm and Face Authentication Performance
ARMATURA’s Multi-Biometric technology combines palm and face authentication with our unique deep learning algorithm to give users an efficient authentication experience. Industry-leading combination of visible and NIR infrared authentication technology provides exceptional authentication accuracy and the industry's top-notch anti-spoofing protection. ISO 19795-2 standard.
Touchless Solution for New standards of the Post-pandemic World
The Omni AC30 meets the needs of the contactless world with features like remote user enrollment, palm, mask detection and face authentication for users with or without masks. Our Palm/ Face/ Card/ QR code authentication technology supports contactless authentication.
Better Images, Faster Authentication
This device supports palm/ face tracking, which can more intelligently capture the user's biometrics and avoid the user's biometric from continuing to be compared after verifying. At the same time, the palm/face AE function enables the device to obtain higher quality images which improves the authentication accuracy
| Face biometric | Dual-camera NIR + visible; ISO 19795-2 anti-spoofing; ~100 ms |
| Palm biometric | 7–15 inch range; ~140 ms; works masked/gloved |
| RFID | EM, HID Prox, iCLASS, Seos, MIFARE, DESFire, FeliCa |
| Apple & Google Wallet | Both Apple Wallet and Google Wallet supported |
| QR & PIN | QR scanning and PIN on the touchscreen |
| Access control | On-board relays, dry contacts, Wiegand I/O, 4 TTL inputs — no separate panel |
| Video intercom | Two-way audio on both AC20 & AC30; one-way SIP video on AC30 |
| Visitor management | Cielo365 QR pass on visitor's phone; pre-registration; time-bound credentials |
| Ingress protection | Dust-tight, high-pressure water jets |
| Operating temperature |
Validated across 80°C envelope |
| NDAA §889 compliant |
Designed in USA · Manufactured in
Thailand · Marketed compliance |
| Protocols | OSDP v2.2 (RS-485) · Wiegand In/Out · TCP/IP · AES-128 |
| Native cloud platform | SaaS, push-protocol over HTTPS, plus Armatura One on-premise |
| Legacy panel coexistence | Coexists with Pro and SpeedFace panels via Cielo365 |
| Tailgating detection | Camera and video available; tailgating analytics roadmap |
